Features
1
Universal type, suitable for wide range of screws, adjustable rail spacing
2
Reliable feeding with high speed, supports 1-out-1 and 1-out-2 configurations
3
Designed for automation equipment with dedicated IO signal communication port
4
Real-time screw counting, fault alarm, adjustable loading and vibration delay parameters
Specifications
| Parameter | Value |
|---|---|
| Screw Spec | φ1.5~5.0mm |
| Screw Length | L≤15mm |
| Feed Speed | 40~60PCS/MIN |
| Capacity | 3000(M2.5*10)PCS |
| Communication | IO |
| Dimensions | 343×165×256mm |
📐Dimensions(mm)
尺寸: 343×165×256mm
